FULL HD 1080P IR Bullet network IP camera, IP 66 with lens

FOB Reference Price:Get Latest Price
US $89-98 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Wellcam
Model Number:
B2.921WF-C-POE
Type:
Digital Camera
Style:
Box Camera
Sensor:
CMOS
Technology:
NetWork
Special Features:
Waterproof / Weatherproof
chip:
HISILICON Hi3516C
Image Sensor:
1/2.8" 2.1Megapixels Progressive Scan Exmor CMOS,IMX122
Day\night:
WDR,Day/Night(ICR),AWB,AGC,BLC
Colour:
White or Black customized
IR LEDs Length:
30-40m
Multiple network monitoring:
Web viewer,CMS,Smart phone
A/V:
support
Lens:
support
Water Proof standard:
IP66
Power Supply:
12V±10%
SupplyAbility
SupplyAbility:
3000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
OEM Package,Neutral Package,Standard carton Package
Port
Shenzhen
Lead Time :
About 3-7 working days after received your payment

                      FULL HD 1080P IR Bullet network IP camera, IP 66 with lens





Features:

 1/2.8" 2.1Megapixels Progressive Scan Exmor CMOS

 H.264 & MJPEG dual-stream encoding

 Max 25/30fps@1080P (1920x1080)

 WDR, Day/Night (ICR), AWB, AGC, BLC

 Multiple network monitoring: Web viewer, CMS, Smart phone.

 Fixed lens 2.8mm, 3.6mm are optional

 Max. IR LEDs Length 10-15M

 IP66, POE





Specification:   2.1MP CMOS Full HD Water-proof



Model

IR

IP66

POE

LENS (2.8mm, 3.6mm)

B2.921WF-C

Yes

Yes

No

Fixed Lens included, 2.8, 3.6mm optional

B2.921-WF-C-POE

Yes

Yes

Yes

Fixed Lens included, 2.8, 3.6mm optional

Camera

Image Sensor

1/2.8” 2.1megapixels Progressive Exmor CMOS

Effective Pixels

1920x1080

Scanning System

Progressive

Electronics Shutter Speed

Auto (1/25,1/30 ~ 1/10000s)

Min. Illumination

0.5Lux/F1.2 (Color), 0.05Lux/F1.2(B/W); 0Lux/F1.2 (IR on)

S/N Ratio

>50dB

Camera Features

Max. IR LEDs Length

10-15M

Day/Night

Auto (ICR) / Color / B/W

Backlight Compensation

BLC / HLC / WDR (digital)

White Balance

Auto

Gain Control

Auto

Noise Reduction

3D

Privacy Masking

Up to 4 Areas

Lens

Focal Length

2.8mm, 3.6mm optional

Max Aperture

F1.4

Focus Control

Manual

Angle of View

92°~ 27°

Lens Type

Fixed Iris

Mount Type

Board-in Type

Video

Compression

H.264 / MJPEG

Resolution

1920x1080, 1280x720 ; 640x320, 320x160, 160x112

Frame Rate

Preferred Stream

1920x1080, 1280x720(1~25/30fps)

Alternate Stream

640x320, 320x160, 160x112 (1~25/30fps)

Bit Rate

32KB ~16Mbps, support VBR, CBR

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4/IPv6, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP,

ONVIF

ONVIF Ver. 2.0

Max. User Access

10 users

Smart Phone

iPhone, iPad, Android, Symbian

General

Power Supply

DC12V, POE (802.3af)

Power Consumption

≤5.5W

Working Environment

-20 °C ~ 60°C

Ingress Protection

IP66,

Dimensions

195.3mm ×82mm ×71.6mm

Weight

0.5KG





B2.920WF-Ca

1193





Packaging & Shipping  20131213_154710

20121124_102906





Our Services



Our Advantage :
Make the reliable IP Cameras for professional surveillance project use.

1. Sagacity R&D engineer team, we aiming developed with Hisilicon Chipset IP Products for 8 years.
(http://www.hisilicon.com ),like HI3518 & HI3520,HI3516 Chipset, skilled in Hardware PCB Detail Layout in China.

2. Adopt using Sony Cmos Sensor IMX Exmor series
(support higher essential video performance to compete Hikvision & Dahua Style Product)

3. We'd like to support related SDK/API Tool synchronize your CMS Server and integrate
    Aptitude design edition , and make customized housing case hardware parts.

4. IP Camera is compatible with Onvif 2.4.1 support, can work with Software Milestones,Exacq,Axxonsoft,Nuuo...
   (http://www.onvif.org/ );

support remote viedo surveillance CMS by IE 11 /Firefox/Chrome browser /App Mobile etc.
Meanwhile we would like to offer you few samples for your available to do real evaluation test &
Welcome to visit China/Shenzhen city to check our factory works……




Company Information

    Wellcam Co., LTD is the factory of Beward Co., LTD( http://www.beward.ru );Famous Brand Ranking Third in Russian Surveillance Area.



Our Services



1. we can offer OEM&ODM

2. we can offer FREE software

3. long time warranty: 36months



FAQ



MOQ

1.Sample t order, have no limit for the quantity.
2.OEM MOQ is 50pcs/model

Payment Terms
T/T, Western Union, PayPal

Delivery Time:
1.Sample order about 2-7 working days.
2. General order about 15-30 working days.
3. Bulk order can about 25-50 working days.
Shipping

 FEDEX,DHL,TNT,UPS,EMS,Aramex,by air,by sea

OEM/ODM Service
OEM and ODM service are acceptable

Warranty Policy
We provide 3 years warranty after the shipment date.

Technical Support
We have professional technical support team to support our customers, and if you have any question for the technology of our products, please email or chat with us by skype or whatsapp,thank you in advance.
