Villa Multi apartment Intercom System outdoor station work with VOIP PBX

FOB Reference Price:Get Latest Price
US $359-380 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Model Number:
1.3 megapixel, color, 1/3 "SONY Exmor, Day / Night
Compression format:
H.264 BP / MP, Motion JPEG
Frame Rate:
Up to 25 fps for all resolutions
G.711 (a-law, u-law), G.726
Housing material:
Viewing Angle:
137 ° (horizontal), 103 ° (vertical)
IR range:
Up to 10 m
DC 12V
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Neutral packing, standard packing and OEM
Lead Time :
About 3-7 working days after received your payment
Video Description
Product Description

Villa Multi apartment Intercom System outdoor station work with VOIP PBX

Support SIP 2.0 - workable with SIP IP phone,IP PBX,linphone application,Asterisk......


Vandal-proof design

Separate emergency call and concierge button

Support for RFID 125 kHz and 13.56 MHz

Video transmission 1.3MP

Duplex audio

Sip 2.0 protocol support

IR Illumination up to 10M

Operating temperature range from -50 +60 C

Support for 9999 subscribers

8 RFID keys per user

Opening the door according to the individual code of the subscriber

Registration of an RFID key by an individual user code

8 calling directions per one subscriber

Possibility to call up to 200 subscribers via coordinate-matrix analog networks(option)

Backup storage for 8500 RFID keys and 1500 codes in case of firmware or restarting the IP doorphone

Removable memory with all settings(USB,pre-installed)

Readiness for working off the basic functionality 1 second after the power supply(access to the entrance,call to analog pipes)

Frost resistant 8-character LED display

Breakout switch end

The possibility of connecting an additional door and a 1-wire reader of it

Possibility of remote lighting control of the entrance

Technical Specification:
Sensor:1.3 megapixel, color, 1/3 "SONY Exmor, Day / Night
Sensitivity:0.01 lx (Day) / 0.003 lx (Night) / 0 lx (with IR illumination on)
Lens:2 mm, F2.0
Viewing Angle: 137 ° (horizontal), 103 °  (vertical)
WDR:Digital,3 presets
Noise suppression: 2D/3DNR (level adjustment),Smart NR
Shutter Speed:From 1/25 to 1/8000 sec. (automatically, setting the maximum value)
Signal/Noise:Not less than 50 dB
Compression format:H.264 BP / MP, Motion JPEG
Video Stream:Double coding: H.264 / MJPEG, H.264 / H.264, MJPEG / MJPEG
Resolution:Main stream: 1280x960 (SXGA), 1280x720 (HD);Sub stream: 720x576, 640x480, 320x240
Frame Rate:Up to 25 fps for all resolutions
Transmission speed:From 32 kbps to 16 Mbps, CBR, VBR
Image Options:Brightness,contrast,sharpness,saturation,exposure,color correction,hue,quality,rotation,
flip,reflection,AGC, white balance,shutter speed (with gain and minimum adjustment)
Audio output:Built-in speaker
Audio Input:Built-in microphone
Compression:G.711 (a-law, u-law), G.726
LEDs:IR LED of the 3rd generation (2 pcs.)
Control:Automatically on / off
Wavelength:850 nm
IR Range:Up to 10 m
Network Interface:10BASE-T/100BASE-TX
Compound:DHCP, static address
Number of doors:2 pcs.
Number of door open sensors:2 pcs.
The sensor of hacking the IP doorphone:Yes
Analog video output:PAL/NTSC 720H
Additionally:Support for microSDHC cards up to 32GB, USB2.0, RS-232TTL or 1-wire
Developments:Motion detection,network error,pressing the call button
Motion Detection:Built-in detector,up to 4 detection zones(sensitivity adjustment)
Sending by mail:By event: frames

Power supply:12V 1 A (DC)
Execution:Vandal proof enclosure
Housing material:Metal
Net weight:1100g
Dimensions (WxHxD):External panel 262x150 mm
System requirements:Microsoft Internet Explorer 9.0 in Windows 8/7 / Vista

More Products
Company Profile

Our advantages:

1.Make the reliable IP security surveillance cameras used for professional surveillance project

2.Strong and experienced R&D engineer team,offer SDK&API for you,meanwhile we can help and support you to develop,revise and integrate to your own system

3.As a developer of professional software and web applications for managing video surveillance systems,we developing commetitive and reliable products that meet the requirement of out customers.


1.Sample t order, have no limit for the quantity
2.OEM MOQ is 50pcs/model

Payment Terms
T/T,Western Union,PayPal

Delivery Time:
1.Sample order about 2-7 working days
2. General order about 15-30 working days
3. Bulk order can about 25-50 working days

FEDEX,DHL,TNT,UPS,EMS,Aramex,by air,by sea

OEM & ODM Service
OEM and ODM service are acceptable

Warranty Policy
We provide 3 years warranty after the shipment date

Technical Support
We have professional technical support team to support our customers, and if you have any question for the technology of our products, please email or chat with us by skype or whatsapp,thank you in advance.
